intersil ADC0802 ADC0803 ADC0804 handbook

Update: 29 September, 2023

The ADC0802 family are CMOS 8-Bit, successive-approximation A/D converters which use a modified potentiometric ladder and are designed to operate with the 8080A control bus via three-state outputs. These converters appear to the processor as memory locations or I/O ports, and hence no interfacing logic is required. The differential analog voltage input has good common-mode rejection and permits offsetting the analog zero-input-voltage value. In addition, the voltage reference input can be adjusted to allow encoding any smaller analog voltage span to the full 8 bits of resolution.

Brand: intersil

File format: PDF

Size: 257 KB

MD5 Checksum: 7CA6C231F4178843CD205AB129F5B4BE

Publication date: 04 July, 2012

Downloads: -

PDF Link: intersil ADC0802 ADC0803 ADC0804 handbook PDF
